Assignment 6: Introduction to RLHF
CMU 11-868 LLM Systems — Fall 2026
Overview
Implement a small reinforcement learning from human feedback (RLHF) pipeline: train a reward model on human preference pairs, then optimize GPT-2 using proximal policy optimization (PPO). The code separates rollout generation from policy updates, taking inspiration from verl and HybridFlow. The provided framework runs on a single device using PyTorch.
The goal is to understand reward learning, token-level advantages, and PPO, and to examine the limitations of optimizing a learned reward. A small reward model and a base GPT-2 model do not guarantee helpful or harmless responses.
Learning objectives and reading
- Train and validate a pairwise preference reward model.
- Implement the provided token-level advantage calculation, clipped PPO objective, and entropy bonus.
- Handle response masks, EOS tokens, and a frozen reference policy correctly.
- Compare held-out reward scores and generated text, including evidence of reward exploitation.
Read the RLHF introduction and PPO paper. The verl documentation and HybridFlow paper provide systems context; implementing their distributed architecture is outside this assignment.
Setup
Use Python 3.10–3.13. A CUDA GPU is recommended for the full training run. CPU is sufficient for the offline unit tests, but full training is much slower. The default pipeline keeps separate policy, reference, and value backbones in memory; lower the rollout batch size and sequence length if memory is limited. Mixed precision and distributed training are not implemented.
git clone https://github.com/llmsystem/llmsys_hw7.git llmsys_hw6
cd llmsys_hw6
python3 -m venv .venv
source .venv/bin/activate
python -m pip install -r requirements.txt
Run all commands from the repository root. Initial model and dataset downloads require network access and sufficient local disk space.
Prepare data
python scripts/prepare_data.py --dataset Anthropic/hh-rlhf --output_dir data --max_samples 10000 --seed 42
python scripts/prepare_data.py --output_dir data --validate
The Anthropic HH-RLHF dataset contains chosen/rejected conversations. Preparation samples from both helpful-base and harmless-base, requires a shared conversation prefix, and keeps final responses between 10 and 500 characters. It retains one pair per unique prompt, shuffles deterministically, and splits examples into 80% training, 10% validation, and 10% test data (with rounding). --max_samples limits the total number of accepted examples before splitting.
| File | Purpose |
|---|---|
data/preference_data.json |
Reward model training pairs |
data/preference_data_val.json |
Reward model validation pairs |
data/preference_data_test.json |
Reward model held-out test pairs |
data/train_prompts.json |
Policy rollout prompts from the training split |
data/val_prompts.json |
Policy validation and checkpoint selection |
data/eval_prompts.json |
Final policy evaluation on the test split |
Prepare the dataset before running the training scripts. Use validation data for checkpoint selection and hyperparameter tuning, and reserve test data for final evaluation. Reward tokenization truncates from the left to retain the final response; long conversation prefixes may be dropped.
Problem 1: Reward model (40 points)
Complete RewardModelTrainer.compute_loss in src/reward_model.py (ASSIGN6_1). The provided model uses a pretrained DistilBERT encoder, its first-token representation, and a scalar reward head.
- Compute one reward per chosen and rejected conversation.
- Use the provided
MarginRankingLosswith margin 1 and positive targets, so chosen responses should receive higher scores. - Return
(loss, chosen_rewards, rejected_rewards): a scalar mean loss and two tensors of shape[batch_size]. Keep the computation differentiable.
The script selects outputs/reward_model/best_reward_model.pt by validation preference accuracy, saves the final model separately, and writes metrics and logs/reward_model_training_curves.png. Preference accuracy is the fraction of pairs with chosen_reward > rejected_reward; ties count as incorrect. Report validation and test accuracy separately. The reward-model experiment must achieve at least 60% validation preference accuracy. Include supporting diagnostics if your run falls below this requirement.
Problem 2: RLHF training with a verl-like framework (40 points)
Complete the three marked sections in src/rlhf_trainer.py:
_compute_gae(ASSIGN6_2_1): the simplified one-step TD advantage calculation described in the code comments._train_step_custom(ASSIGN6_2_2): clipped surrogate policy loss and entropy bonus._compute_entropy(ASSIGN6_2_3): categorical entropy from logits, averaged over supplied valid response states.
Use one-step TD targets: each valid response state receives its immediate reward plus a discounted next-state value, and its advantage is the target minus its current value. The final response state receives the sequence reward with zero bootstrap value. ppo_gae_lambda is unused in this simplified calculation.
The caller supplies a response-state mask: state position t predicts token t+1. Include the first EOS action, exclude padding and prompt-only states, and return zeros outside the mask. The other two TODOs implement the standard clipped PPO surrogate and categorical entropy.
Training rollouts sample from the unmodified policy distribution (temperature 1, top-p 1, top-k disabled), matching the log probabilities used by PPO. Evaluation may use temperature/top-p sampling. rollout_max_length is the total prompt-plus-response token limit; prompts are truncated to half that length. Each rollout batch is updated as a whole for verl.ppo_epochs.
The script uses validation prompts to select outputs/rlhf_model/best_rlhf_model, saves final_rlhf_model and per-epoch training checkpoints, and writes plots/rlhf_training_curves.png. Full training checkpoints include optimizer, reference, and value weights and can be substantially larger than inference model directories.
Problem 3: Evaluation and analysis (20 points)
python scripts/evaluate.py --base_model gpt2 \
--rlhf_model outputs/rlhf_model/best_rlhf_model \
--reward_model outputs/reward_model/best_reward_model.pt \
--num_samples 3 --max_prompts 100
--rlhf_model accepts the actual directory containing a Hugging Face model and tokenizer. --reward_model accepts the exact reward checkpoint file. Without these arguments, evaluation searches for the best checkpoint and then the final checkpoint in the configured output directories. Without a policy checkpoint, it evaluates only the base model.
Inspect plots/reward_comparison.png and the generated samples in evaluation_results/ to compare the base and trained policies. Use the same held-out prompts and generation settings for both models.
You may observe incoherent generations receiving high rewards: this can indicate reward exploitation. A higher learned reward alone does not establish that the responses are more helpful or harmless. Differences between independently sampled rewards are not human preference win rates.
Configuration
All three training/evaluation commands accept --config path/to/config.yaml. Explicit command-line arguments override YAML values; omitted arguments preserve them. Configuration sections are defined in src/config.py. For example:
training:
reward_num_epochs: 3
ppo_num_epochs: 2
ppo_learning_rate: 1.0e-6
verl:
rollout_batch_size: 2
rollout_max_length: 128
ppo_epochs: 4
experiment:
seed: 42
For PPO, training.ppo_kl_penalty controls the reference KL coefficient (default 0), training.ppo_value_coef weights value regression, and training.ppo_entropy_coef controls entropy regularization. verl.ppo_clip_eps controls PPO clipping. The submission script includes the effective configurations and package versions.
Tests
Tests run offline on CPU using small, locally initialized models. Complete the marked TODO sections and run the tests before submitting. Unfinished sections raise NotImplementedError.
scripts/check_implementation.py is the student self-check tool. It runs the public tests with Hugging Face downloads disabled and writes per-test feedback to self_check.json and self_check.log. Exit codes are 0 for passing all tests, 1 for failed/skipped tests, and 2 for setup errors or timeout (default 300 seconds; change with --timeout).
Submission and grading
| Problem | Points | Evidence |
|---|---|---|
| Reward model | 40 | Pass the reward-model tests and achieve at least 60% validation preference accuracy |
| RLHF training | 40 | Complete the trainer TODOs, pass the relevant tests, and demonstrate reward improvement in plots/rlhf_training_curves.png |
| Evaluation | 20 | Run the base/trained comparison and submit plots/reward_comparison.png with its metrics and generated samples |
Compare rewards before and after RLHF training using the same trained reward model. If the reward does not improve, include a brief explanation with your results.
Build the submission
Do not upload model weights, training checkpoints, datasets, or virtual environments. Keep the selected reward and policy checkpoints locally; staff may request them separately if needed. The regular submission is limited to 50 MiB compressed and uncompressed, with a 10 MiB limit per file.
After completing the three experiments, run the submission command below. The training/evaluation scripts automatically save the effective configurations as logs/reward_model_config.yaml, logs/rlhf_config.yaml, and logs/evaluation_config.yaml. These include the seed and resolved command-line overrides. Use the default output directories for submission.
You may optionally attach notes with --report report.md (or PDF) and exact commands with --commands commands.txt.
The script creates assignment6_YOUR_ANDREW_ID.zip. Missing experiment evidence stops packaging and identifies the missing file. The script also runs the public student self-check and includes its JSON feedback. You can package a submission with failed implementation tests. Resolve setup errors before packaging. The script never deletes local checkpoints or overwrites an existing archive; use --output another_name.zip for a new archive.
The archive includes only:
- Python source under
src/,scripts/, andtests/, plus the README and requirements. - Generated
package_versions.txtand studentself_check.jsonfeedback, plus notes or commands if you supplied them. - Small metrics, configurations, plots, and sample outputs from
logs/,plots/, andevaluation_results/. - A
submission_manifest.jsonrecording your Andrew ID, file sizes, and SHA-256 hashes.
Required experiment evidence is:
logs/reward_model_metrics.json
logs/rlhf_training_metrics.json
logs/reward_model_config.yaml
logs/rlhf_config.yaml
logs/evaluation_config.yaml
logs/reward_model_training_curves.png
plots/rlhf_training_curves.png
plots/reward_comparison.png
evaluation_results/detailed_comparison.json
evaluation_results/base_model_outputs.json
evaluation_results/rlhf_model_outputs.json
outputs/, data/, hidden files, caches, model weight formats, and environment folders are excluded. Symlinks are rejected. If a plot or JSON file exceeds the limit, reduce image resolution or the number of saved evaluation samples and regenerate the archive. Submit the generated ZIP, not the repository folder or a manually zipped outputs/ directory.
